ETFE美國科慕200 乙烯四氟乙烯共聚物 薄膜管材應用F40鐵氟龍

Generic Name: 乙烯四氟乙烯共聚物 (ETFE) - 提供方: The Chemours Company

Description
Tefzel ? ETFE 200 is a general-purpose fluoroplastic resin available in translucent, 2.5-mm (0.1-in.) pellets. Compared to other grades of Tefzel ? , its most unique features are an intermediate flow rate and a balance of properties that make it suitable for a variety of processes and demanding end uses.

Tefzel ? ETFE 200 and the other Tefzel ? fluoroplastics are melt processible, modified copolymers of ethylene and tetrafluoroethylene. They are high-performance resins that can be processed at relatively high rates, compared to fluorocarbon resins. They are mechanically tough and offer an excellent balance of properties. Tefzel ? ETFE 200 can perform successfully in applications where other thermoplastics are lacking in mechanical toughness, broad thermal capability, ability to meet difficult environmental conditions, or limited by fabricating problems.

Properly processed products made from virgin Tefzel ? ETFE 200 are inert to most solvents and chemicals, hydrolytically stable, and weather-resistant. Recommended upper service temperature is 150 °C (302 °F); useful properties are retained at cryogenic ranges. The level and stability of dielectric properties are excellent, and the flame rating is V-0 by the UL94 method. Mechanical properties include outstanding impact strength, cut-through, and abrasion resistance. High energy radiation resistance meets IEEE 383, and the resin is approved for nuclear power plant use.

Statements, or data, regarding behavior in a flame situation are not intended to reflect hazards presented by this or any other material when under actual fire conditions.

Typical End Products
Tefzel ? ETFE 200 is ideal for many end products, including electrical components, such as sleeving, coil forms, sockets, connectors, and switches; lab ware, such as tubing, valves, containers, and dishes; battery or instrument components that require chemical inertness; chemical service items, such as valve components, seal glands, pipe plugs, and corrugated tubing; and film.

 與典型值比較 - Upgrade to compare!

單位: SI

總覽
材料狀態

已商用：當前有效

資料 1

Technical Datasheet (English)

搜索 UL 黃卡

The Chemours Company

Tefzel?

供貨地區

北美洲

拉丁美洲

歐洲

亞太地區

特性

高抗撞擊性

共聚物

抗伽馬輻射

抗溶劑性

良好的電氣性能

耐候性，良好

耐化學品性能，良好

耐磨損性，良好

韌性良好

水解穩定

通用

中等流動性

用途

薄膜

電氣/電子應用領域

閥門/閥門部件

管道系統

管件

機器/機械部件

緊固件

開關

連接器

密封件

容器

實驗室器具

機構評級

IEEE 383

外觀

半透明

形式

粒子

加工方法

Transfer Molding

吹塑成型

擠出

壓縮模塑

注射成型

物理性能

額定值

單位制

測試方法

密度 / 比重

1.70

g/cm3

ASTM D792熔流率（熔體流動速率）

7.0

g/10 min

ASTM D3159吸水率 (24 hr)

7.0E-3

%

ASTM D570機械性能

額定值

單位制

測試方法

抗張強度 (23°C)

45.0

MPa

ASTM D3159伸長率 (斷裂, 23°C)

300

%

ASTM D3159彎曲模量 (23°C)

1200

MPa

ASTM D790壓縮強度

38.0

MPa

ASTM D695沖擊性能

額定值

單位制

測試方法

無缺口懸臂梁沖擊 (23°C)

無斷裂

ASTM D4812硬度

額定值

單位制

測試方法

肖氏硬度 (邵氏 D)

67

ASTM D2240熱性能

額定值

單位制

測試方法

熔融溫度

255 到 280

°C

ASTM D3159線形熱膨脹系數 - 流動 (0 到 100°C)

1.3E-4

cm/cm/°C

ASTM D696Service Temperature

< 150

°C

UL 746電氣性能

額定值

單位制

測試方法

體積電阻率

1.0E+17

ohms·cm

ASTM D257介電強度 (0.254 mm)

70

kV/mm

ASTM D149介電常數 (23°C, 1 MHz)

2.50 到 2.60

ASTM D1531耗散因數 (23°C, 1 MHz)

8.0E-3

ASTM D1531耐電弧性

122

sec

ASTM D495可燃性

額定值

單位制

測試方法

極限氧指數

30 到 32

%

ASTM D2863
